    High-performance PC in a compact and classy format

    TUXEDO Infinity S - Gen1



    Full-featured desktop PC in a compact and elegant aluminum enclosure.

    You associate desktop PCs with huge, bulky towers in a boxy and boring case design?

    Time to change your mind! The TUXEDO Infinity S(mall) series combines high-performance hardware with a space-saving Small Form Factor (SFF) in an infinitely elegant-looking, high-quality metal design.

    Compact Aluminium case
    169 x 273 x 340 mm | 5,6 kg

    Full-size graphics cards
    Length max. 325 mm | Dual-Slot

    Powerful cooling options
    240 LCS radiator | 2x 120 mm fans

    Mini-ITX
    Mainboard standard

    With relatively compact dimensions of 169 x 273 x 340 mm and an empty weight of 5.6 kg, the SFF Linux PC relies on the Mini-ITX mainboard standard and even supports full-sized, dual-slot graphics cards with a length of up to 325 mm for great performance as a workstation or gaming PC.

    Thanks to its simplistic, elegant case design in 2 available colors, subtle black or noble silver, the Infinity-S-Gen1 blends equally nice into the office, your study or living room.

    Icon Gehäuse

    Compact and elegant aluminum case in 2 colors

    169 x 273 x 340 mm | 5,6 kg

    Icon Kühlung

    Powerful cooling options

    240 LCS radiator | 2x 120 mm fans

    Icon CPU

    Up to

    Intel Core i9-13900

    24 Cores | 32 Threads | 65 Watts TDP

    Icon GPU

    Optional

    High-performance graphics from NVIDIA and AMD

    Geforce RTX vs Radeon RX

    Icon Speicher

    Up to

    64 GB (2x 32 GB) RAM

    SSD: 2x 2,5'', 2x M.2 | HDD: 1x 3,5''

    Icon Anschlüsse

    10x USB | WiFi | HDMI & DisplayPort | up to 3 Displays*

    * incl. MST hub

    Icon Netzteil

    Power supply with up to 750 Watts

    SFX | SFX-L



    Technical Details

    Chassis

    High-quality and elegant aluminium case in 2 colors (silver and black).

    Dimensions: 169 mm x 273 mm x 340 mm

    Materials:
    Top plate: 3 mm aluminum magnesium alloy
    Front plate / back plate / bottom plate: 2 mm aluminum magnesium alloy
    Hardware: 1.5 mm all black steel plate
    Side panel: 3.00 mm all tempered glass

    Power supply:
    Certification: 450W: 80+ Bronze | 750W: 80+ Platinum
    Voltage: 230V
    Power output: 450W or 750W. From NVIDIA RTX or AMD RX graphics the 750W power supply is needed!
    Power usage: depending on hardware and system load
    Noise level: Temperature controlled Silent fan



    Cooling options:
    Top and bottom:  2x 120 mm fans (optional)
    Top: 240 mm Liquid Cooling Radiator (optional)

    Noise growth / Cooling / Ventilation / Fan
    Temperature controlled silent fan!
    At low system workload/stress there is less heat emerging. The cooling system fans have to spin accordingly fast or slow or even turn themselves off completely. But the device doesn't produce any disturbing noises even at full load, no high frequency sounds or clatter, just air swooshing.



    Ports

    Front:
    - Power button
    - USB-A 3.0
    - USB-C 3.1 Gen2



    Main processor


    High power CPUs capable for all tasks

    • Intel Core i3-13100
      4 cores (4 Performance-cores | 0 Efficient-cores) | 8 Threads | Max. 4,5 GHz | 12 MB Cache | 60 W TDP
    • Intel Core i5-13500
      14 cores (6 Performance-cores | 8 Efficient-cores) | 20 Threads | Max. 4,8 GHz | 24 MB-Cache | 65 W TDP
    • Intel Core i7-13700
      16 cores (8 Performance-cores | 8 Efficient-cores) | 24 Threads | Max. 5,2 GHz | 30 MB-Cache | 65 W TDP
    • Intel Core i9-13900
      24 cores (8 Performance-cores | 16 Efficient-cores) | 32 Threads | Max. 5,6 GHz | 36 MB-Cache | 65 W TDP



    Graphics card

    The power efficient graphics chip integrated in the processor can be supersedet by a more powerful NVIDIA GeForce or AMD Radeon RX graphics card.
    For details, please have a look at the configurator.



    Memory

    Type: DDR5 DIMM
    Manufacturer and speed see configurator
    Default and maximum see configurator
    Dual channel mode (with 2 modules)



    Mass storage (SSD / HDD)

    See "Storage connectors" under "Mainboard



    Mainboard

    Mainboard:
    Manufacturer & Chipsatz: Intel B760 Chipset
    256 Mbit AMI UEFI BIOS
    Formfactor: Mini-ITX (17 x 17 cm)

    Network / Ethernet / LAN
    - 1x LAN:
        - 1x 2.5 Gigabit Realtek 8125BG (2.5 Gbit / 1 Gbit / 100 Mbit)
        - Supports Wake-On-LAN
        - Supports PXE

    Wireless LAN / WLAN / WIFI
    Intel Wi-Fi 6 AX200 Series
    - Supports MU-MIMO TX/RX, 2.4GHz/ 6GHz (160MHz) up to 2.4Gbps
    - Supports 802.11 a/b/g/n/ac/ax
    - Supports Bluetooth 5.2

    Sound / Audio:
    7.1 CH HD Audio (Realtek ALC897 Codec)
    - High Definition Audio
    - 2/4/5.1/7.1-channel

    Rear Mainboard connectors:
    1x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
    1x DisplayPort 1.4
    1x HDMI Port 2.1 (4K@60Hz) with HDR
    2x USB-A USB 2.0
    4x USB-A USB 3.2 Gen1 5GBit/s (backward compatible)
    1x USB-A USB 3.2 Gen2 10GBit/s (backward compatible)
    1x USB-C USB 3.2 Gen2 10GBit/s (backward compatible)
    2x Antenna connectors
    3x Audio: 1x Line in; 1x Line-Out; 1x microphone

    TUXEDO Intel B760 Mainboard

    Mainboard connectors internally (partially populated by your configuration):
    2x DDR5 DIMM sockets
    1x PCI Express 5.0 x16 slot, running at x16
    4x SATA 6Gb/s connector(s)
    2x M.2 slots
    1x CPU Fan
    1x Pump Fan
    1x System Fan
    2x Front Panel
    1x Chassis Intrusion
    1x Front Audio
    1x Addressable V2 RGB LED connector
    1x RGB LED connector
    1x TPM pin header (Support TPM 2.0)
    2x USB 2.0
    2x USB 3.2 Gen1 Type A
    1x USB 3.2 Gen2 Type C

    Storage connectors:

    1x M.2 Socket (M2_1)
    - Supports M Key type 2280 M.2 PCI Express module up to Gen4 x4
    1x M.2 Socket (M2_2)
    - Supports M Key type 2280 M.2 PCI Express module up to Gen4 x4 & SATA 6Gb/s
    4x SATA 6Gb/s







    System & Service

    Operating systems

    We install Ubuntu and TUXEDO OS (based on Ubuntu with KDE Plasma Desktop) in the latest 64-bit version with long term support.

    With our fully automatic installation WebFAI you can easily perform a Linux installation exactly as we at TUXEDO Computers do it in our production! You can choose from all distributions that we also offer in our configurator. Depending on the distribution, you have the choice between different desktop interfaces. More backgrounds and a video demo as well as detailed instructions can be found here.



    For "self-installers" and all who are interested, we have set up a database with downloads, instructions, tips & tricks and offer Tomte, a tool that automatically makes our adjustments under Ubuntu, elementary OS and Linux Mint:





    Encrypted Installation

    On request, we install your Linux system completely encrypted. The pre-installation as dual boot with Windows is technically not possible.
    Further details as well as a detailed introduction to encryption can be found here.



    Windows on request

    If you don't want or can't do without Windows, we install the desired Windows version next to Linux or alone. Please understand that a dual-boot installation can take 1-2 working days longer, even though the process is fully automatic. Please also note that we provide you with a correct Windows license incl. license sticker and installation DVD!



    Windows Drivers

    The corresponding Windows drivers are already included as standard with every device, regardless of whether it is with or without Windows or operating system installation. Alternatively, you are free to download all Windows-Drivers from here.



    Warranty

    2 years pick up and return (12 months on wearing parts like battery & power supply)

    Optional: Up to 5 years pick up and return (12 months on wearing parts like battery & power supply)



    All devices have a maintenance-friendly design. Depending on the model, the essential hardware components such as processor, drive, hard disks, RAM, WIFI modules etc. can be accessed via maintenance flaps or removable floor trays. Furthermore the battery is replaceable if not stated differently. Of course even after expiration of your warranty period we're offering replacement parts and service for many years!



    For warranty cases we'll provide you with free return label after getting in touch with us. Warranty handling is done via our technical support. Please note our warranty conditions



    Package Contents

    1x TUXEDO preinstalled & configured
    1x power cord
    1x First steps manual incl. short technical manual
    1x Mainboard manual
    1x WebFAI USB drive (www.webfai.de) for Linux recovery
    1x TUXEDO fan stuff package
