TUXEDO InfinityBook because it is a TUXEDO notebook with almost infinite possibilities. Mobility, running time, performance, quality and flexibility in a single device with unibody completely made of aluminium! Combined with the elementary OS or Ubuntu Linux specially adapted for this notebook, it is a unique device with a unique user experience.
The completely new developed InfinityBook Pro 13 has a completely made of aluminium housing.
For better protection, the upper and lower shells cover the valuable hardware like a book cover - in a book cover kinda design.
In addition, it has two continuous rubber feet to ensure optimum grip even over corners.
The illuminated keyboard with penguin-super-button in full DIN-A4 size is also a novelty in this class. Even multiple typists can use it on the go without having to long for their stationary keyboard ;)
The Pro version of our InfinityBook series is uncompromisingly designed for maximum performance and best features, paired with a battery life of up to 12 hours.
To live up to this claim, Intel's 13.3-inch InfinityBook Pro contains Intel's strongest Ultrabook processor Core i7 with two kernels and four threads and up to 3.5 GHz per core!
Despite the low weight of only approx. 1.3kg and a height of only 18mm, the device can accommodate a 2.5" hard disk as HDD or SSD as well as an M. 2 format SSD with SATA or NVME/PCIe connection. Of course, it is also possible to install an 4G/LTE module and the obligatory WLAN/Bluetooth module.
Tidy computing power paired with a lot of storage space, only enough memory is missing.
And the InfinityBook Pro 13 has no shortage of this either. Two slots are available which can hold up to 32GB DDR4 RAM.
The InfinityBook Pro 13 does not make any compromises on the connection side either:
A Mini-DisplayPort, an HDMI connection, a Gigabit LAN port, a USB type C with Thunderbolt 3 and several USB ports and connections for headphones and microphone are available.
The USB type C is a further highlight, because besides USB 3.1 Gen2 (10Gb/s) it also masters Thunderbolt 3 and DisplayPort!
Of course, there is also an integrated webcam and a microphone, two loudspeakers, a touchpad with separate mouse buttons, a multi-card reader and the obligatory illuminated keyboard - in the German and US version with penguin super key :D (instead of the windows symbol).
The illuminated full-size keyboard is also a pleasure for many typists. It has a clear and rather hard keystroke and enough key stroke to keep the tipper in a good mood even when writing for a long time. A keyboard that can only be found on 15 and 17 inch devices!
After removing the underside of the housing, all components are easy to maintain, clean or replace.
Display / Monitor
Modern displays with IPS panels have bright areas along the frame as a normal characteristic. This has hardly any influence on everyday operation, not least because the displays are optimized for daylight operation. It can only be minimized, but not completely avoided, regardless of the manufacturer and for manufacturing reasons. Details on pixel error classes can be found here.
Type: LED backlight display
Size: 13.3" (33.78cm)
The opening angle of the display hinges is about 135°.
Resolution: Full-HD IPS-Panel, 1920 x 1080, matte/non-glare
Brightness: 350cd/m²
Contrast: 1000:1
max. Viewing angle: 89°
Resolution: QHD+, 3200 x 1800, matte/non-glare
Brightness: 350cd/m²
Contrast: 800:1
max. Viewing angle: 85°
Model: LG LP133QD1-SPB3
Chassis
Material: aluminium, plastic display frame
Unibody consisting of 4 parts: Display top shell, housing bottom shell, display frame and keyboard shell. Except for the display frame, all parts are completely made of aluminium.
Dimensions: Width: 329,8mm; Height: 17,8mm; Depth: 225,0mm
Weight: approx. 1.3 kg incl. battery, depending on equipment
Maintenance: After opening the base plate with a series of screws, all components and fans are easily accessible, easy to maintain, clean and replace.
Here you find a picture gallery with photos of the brown/silver case: https://mytuxedo.de/index.php/s/kHSdUxiGnsG527G
Ports
2x USB 3.1 Typ-A Gen1 up to 5Gbit/s
1x USB Typ-C with Thunderbolt 3
1x MiniDisplayPort 1.3
1x HDMI 1.4b with HDCP (max. 2560X1600@60Hz; 3840x2160@30Hz)
1x Headphones
1x Microphone
1x Gigabit-LAN-Port
1x Charging port
1x Card-Reader
1x Kensington
Battery & power supply
Large 36 Wh lithium-ion battery. (Interchangeable after opening the base plate.
Mini power supply unit, only 88x35x26mm (LxWxH), 100g or 200g with all cables, 40W 19V 2.1A
Battery runtime
Approx. 12 hours tested with TUXEDO Xubuntu and Ubuntu 16.04 with 32GB RAM, 512GB Samsung 960 Pro M. 2 NVME and Kernel 4.11.1.
We're testing battery time always in idle mode, at minimal display brightness, with keyboard backlight deactivated, Wi-Fi & Bluetooth disabled and without any further connected devices (USB, LAN, HDMI, VGA etc. unplugged!). We always test with integrated graphics when a dedicated and integrated graphics chip is installed.
This way you get an information of maximal possible battery life. Starting from this, you can manage your individual battery life depending on your demands and to influence it, e.g. is keyboard backlight unnecessary during daylight. Bluetooth is also only needed to be turned on, if there's a Bluetooth device connected. Full display brightness as well is hardly always necessary.
Runtime tests of Notebookcheck:
Idle (without WIFI, min. brightness): 13h 19min
Surfing via WIFI v1.3: 7h 28min
Load (full brightness): 3h 00min
Main processor
Energy efficient Intel Core-i Mobile-CPU:
Intel Core i5-8250U (4x 1.6-3.4GHz Quad-Core, 8 Threads, 6MB Cache, 15W TDP)
Intel Core i7-7500U (2x 2.7-3.5GHz Dual-Core, 4 Threads, 4MB Cache, 7,5-15W TDP)
Intel Core i7-8550U (4x 1.8-4.0GHz Quad-Core, 8 Threads, 8MB Cache, 15W TDP)
Graphics card
Energy-saving graphic chip integrated in the CPU:
Intel UHD Graphics 620
Memory
Type: DDR4 SO-DIMM
Manufacturer and speed see configurator
Default and maximum see configurator
Dual channel mode (with 2 or 4 modules)
Current Laptop-U-CPUs do support 2400MHz RAM officially. So even 2666MHz RAM is shown with 2400MHz inside the system. But in fact, the high-performance-RAM with 2666MHz squeezes around 5% more performance out of your laptop!
Hard drive
Standard 2,5" HDD or SSD, max. 7mm height
Manufacturer and speed see configurator
Standard and maximum see configurator
Mass storage (SSD / HDD)
Fast M.2 SSDs
Manufacturer and speed see configurator
Standard and maximum see configurator
Communication / Network
Wired/LAN: Gigabit LAN (Realtek RTL8168/8111 Ethernet, 10/100/1000 Mbit)
Wireless/WIFI (optional):
Intel Dual Band Wi-Fi 6 AX 200 & Bluetooth (M.2 2230):
Interface: M.2 2230
Wireless LAN / WLAN standards: 802.11 ac/a/b/g/n/ax
DualBand 2,4 / 5 GHz
Communication channels: 2x2
Transfer rate: 300 Mbit/s (2.4GHz WIFI) / 2,4Gbps (5GHz WIFI)
Bluetooth:
Integrated in above Intel Dual Band Wi-Fi AX 200
Version: Dual Mode Bluetooth 5.1
LTE module
LTE/HSDPA+ 4G Huawei ME936
Form factor: M.2 Interface
Supported frequency bands
LTE (FDD): B1/B2/B3/B4/B5/B7/B8/B13/B17/B20
HSPA+/HSPA/UMTS: B1/B2/B4/B5/B8
EDGE/ GPRS/GSM: 1900/1800/900/850 MHz
Transfer rates
LTE FDD: ↑ 50 Mbps ↓ 100 Mbps
HSPA+: ↑ 11 Mbps ↓ 42 Mbps
WCDMA: ↑ 384 kbps ↓ 384 kbps
GPS
GPS Standalone, A-GPS, GPS XTRA, Glonass
LTE/HSDPA+ 4G Huawei ME906s
Form factor: M.2 Interface
Supported frequency bands
LTE (FDD): B1/B2/B3/B5/B7/B8/B20/B28
HSPA+/HSPA/UMTS: B1/B2/B5/B8
EDGE/ GPRS/GSM: 1900/1800/900/850 MHz
Transfer rates
LTE FDD: ↑ 50 Mbps ↓ 150 Mbps
HSPA+: ↑ 5.76 Mbps ↓ 42 Mbps
WCDMA: ↑ 384 kbps ↓ 384 kbps
GPS
GPS Standalone, A-GPS, GPS XTRA, Glonass
Webcam / Laptop camera
2,0 Megapixel (2,0 MP) camera including microphone and "Windows Hello" function
Sound / Audio
High Definition Audio
2 speakers: 2x 2W
Integrated microphone
Card reader
9-in-1 Card Reader
- MMC / RSMMC
- SD / SDHC / SDXC / Micro SD (Adapter necesssary)
- MS / MS Pro / MS Duo
Operating systems
We install Ubuntu and TUXEDO OS (based on Ubuntu with KDE Plasma Desktop) in the latest 64-bit version with long term support.
With our fully automatic installation WebFAI you can easily perform a Linux installation exactly as we at TUXEDO Computers do it in our production! You can choose from all distributions that we also offer in our configurator. Depending on the distribution, you have the choice between different desktop interfaces. More backgrounds and a video demo as well as detailed instructions can be found here.
For "self-installers" and all who are interested, we have set up a database with downloads, instructions, tips & tricks and offer Tomte, a tool that automatically makes our adjustments under Ubuntu, elementary OS and Linux Mint:
Encrypted Installation
On request, we install your Linux system completely encrypted. The pre-installation as dual boot with Windows is technically not possible.
Further details as well as a detailed introduction to encryption can be found here.
Windows on request
If you don't want or can't do without Windows, we install the desired Windows version next to Linux or alone. Please understand that a dual-boot installation can take 1-2 working days longer, even though the process is fully automatic. Please also note that we provide you with a correct Windows license incl. license sticker and installation DVD!
Windows Drivers
The corresponding Windows drivers are already included as standard with every device, regardless of whether it is with or without Windows or operating system installation. Alternatively, you are free to download all Windows-Drivers from here.
Warranty
2 years pick up and return (12 months on wearing parts like battery & power supply)
Optional: Up to 5 years pick up and return (12 months on wearing parts like battery & power supply)
All devices have a maintenance-friendly design. Depending on the model, the essential hardware components such as processor, drive, hard disks, RAM, WIFI modules etc. can be accessed via maintenance flaps or removable floor trays. Furthermore the battery is replaceable if not stated differently. Of course, even after expiration of your warranty period, we're offering replacement parts and service for many years!
For warranty cases, we'll provide you with a free return label after getting in touch with us. Warranty handling is done via our technical support. Please note our warranty conditions
Package Contents
1x TUXEDO Book preinstalled & configured
1x Power supply
1x Power cord
1x Recharchable battery
1x First steps manual incl. short technical manual
1x WebFAI USB pendrive (www.webfai.de) for Linux recovery
1x Drivers for Windows downloadable
Noise growth / Cooling / Ventilation / Fan
Temperature controlled silent fan
At low system workload/stress there is less heat emerging. The cooling system fans have to spin accordingly fast or slow or even turn themselves off completely. But the device doesn't produce any disturbing noises even at full load, no high frequency sounds or clatter, just air swooshing.
Custom fan control with the TUXEDO Control Center
With the TUXEDO Control Center you are able to control the behavior of the fans at yourself. This means that you get the ability to make your device as silent as possible. You are able to set the device almost passive cooled, without any fan noise most of the time!
